Cooler Master TD500 RGB

Regular price
$99
Sale price
$99
Regular price
Sold out
Unit price
per
Shipping calculated at checkout.

Model
Brand Cooler Master
Series MasterBox TD500 Mesh w/ Controller
Model MCB-D500D-KGNN-S01
Details
Type  ATX Mid Tower
Color Black
Case Material Steel / Plastic / Tempered Glass
With Power Supply No
Power Supply Mounted  Bottom
Motherboard Compatibility  Micro ATX / ATX / Mini ITX / E-ATX (up to 12" x 10.7" motherboards)
Side Panel Window  Yes
LED  Addressable RGB
Dust Filters  Front, Top, Bottom
Expansion
Internal 3.5" Drive Bays 2 x 3.5" / 2.5" Combo
Internal 2.5" Drive Bays 4 (2 + 2 Combo)
Expansion Slots  7
Front Panel Ports
Front Ports 2 x USB 3.2 Gen 1 (USB 3.0) / Audio / ARGB Controller
Cooling System
Fan Options Front: 3 x 120mm (3 x 120mm ARGB fans Pre-installed) or 2 x 140mm fan

Top: 3 x 120mm or 2 x 140mm fan

Rear: 1 x 120mm fan
Radiator Options Front: 120 / 140 / 240 / 280 / 360mm

Top: 120 / 240 / 360mm (44mm max motherboard component height)

Rear: 120mm
Dimensions & Weight
Max GPU Length 410 mm
Max CPU Cooler Height 165 mm
Max PSU Length 180 mm
Dimensions (H x W x D) 18.50" x 8.50" x 19.40"
Weight 15.32 lbs.
Additional Info
Features Polygonal Mesh features a three-dimensional contour and is also capable of simultaneously providing high airflow and dust filtration. .

A Crystalline Tempered Glass side panel dons a crystalline design, precision engineered for strength as well as aesthetics

Three included addressable RGB fans flood the build with lighting while providing considerable airflow.

For enthusiast-grade cooling, two 360mm radiators are supported on the top and front panel to keep the most extreme systems cool.

Support for up to seven 120mm fans and front, top, and rear liquid cooling ensure the utmost in performance.
